产品名称:7.4V3.0公斤微型数码舵机 Product Name:7.4V3.0kg-cm Micro Digital Servo |
产品型号 Item No: XQ-S1009D |
1.使用环境条件 Apply Environmental Condition |
|
No. | Item | Specification |
1-1 | 存储温度 Storage Temperature Range | -20℃~70℃ |
1-2 | 运行温度 Operating Temperature Range | -15℃~65℃ |
2.测试环境 Standard Test Environment |
|
No. | Item | Specification |
2-1 | 温度 Temperature range | 25℃ ±5℃ |
2-2 | 湿度 Humidity range | 65%±10% |
3.机械特性 Mechanical Specification |
|
No. | Item | Specification |
3-1 | 尺寸 Size | 23.5*9*19.5 mm |
3-2 | 重量 Weight | 7.7 g no including accessory |
3-3 | 齿轮类型 Gear type | Aluminium |
3-6 | 机构极限角度 Limit angle | 360° |
3-7 | 轴承 Bearing | 2 Ball bearings |
3-8 | 出力轴 Horn gear spline | 15T-φ3.85mm |
3-9 | 摆臂 Horn type | Plastic,POM |
3-10 | 外壳 Case | Aluminium CNC |
3-11 | 舵机线 Connector wire | 145mm ±5mm |
3-12 | 马达 Motor | Coreless motor |
3-13 | 防水性能 Water proof | No |
4.电气特性 Electrical Specification (Function of the Performance) |
|
No. | 工作电压 Operating Voltage Range | | |
4-1 | 空载速度 No load speed | | |
4-2 | 空载电流 Runnig current(at no load) | | |
4-3 | 堵转扭矩 Peak stall torque | | |
4-4 | 堵转电流 Stall current | | |
|
No. | 工作电压 Operating Voltage Range | 6.0 V | 7.4 V |
4-1 | 空载速度 No load speed | 0.09 sec/60° | 0.07 sec/60° |
4-2 | 空载电流 Runnig current(at no load) | 150 mA | 200 mA |
4-3 | 堵转扭矩 Peak stall torque | 2.5 kg.cm | 3.0 kg.cm |
4-4 | 堵转电流 Stall current | 0.8 A | 1.2 A |
