产品特色
摇头开关1A系列,最高RATING可以使用到5A,采用防水密封的设计来避免因焊接或清理过程中的污染物侵入而影响正常的开关功能,有SPDT、DPDT、3PDT等规格可选择,铜头和底座材质皆符合尼龙UL94V-0标准。
规格说明
Contact Rating: (1) 5Amps with resistant load @ 120 VAC or 28 VDC (2) 2Amps with resistant load @ 250 VAC
Mechanical Life: 30,000 make-and-break cycles.
Contact Resistance: 10 mΩ max. initial @2-4VDC, 100mA for both silver and gold plated contacts.
Insulation Resistance: 1,000 mΩ min.
Dielectric Strength: 1,000 Vrms min. @sea level.
Operating Temperature: -30°C to 85°C
产业应用
电信、仪器、测试设备、医疗设备。
