AUAVT AT-100

品牌：AUAVT
最小起订：1
有效期至：长期有效
更新时间：2015-11-20 15:12
立即询价

加入收藏

普通商家

英国AdvancedUAVTechnology公司
经营模式：经销和服务商
地区：海外英国
电话：400-003-8030
进入店铺

联系方式

企业推荐产品

更多>

产品详情

产品参数

产品图片

AT-100 Medium weight, medium endurance VTOL UAV

We are redesigning the AT 100 with a new frame
Fully autonomous flight with auto takeoff and landing.
Day video standard, other cameras, video, and sensor packages optional.
Up to 2.5 hour flight time
1.5km standard telemetry range (long range optional)

Length: 1470 mm
Width: 510 mm
Height: 685 mm
Main rotor diameter: 2010 mm
Tail rotor diameter: 360 mm
Dry weight: 16 Kg
Engine: 23cc Gasoline or 3.4kW Elect.
On board Generator: 150 W 12V with batt. backup
Climb rate: 122/m/min (AFCS Limited)
Maximum speed: 120 Km/h (AFCS Limited)
Endurance: Up to 2 h gas / 45 min Elect.
Maximum payload: 8 Kg
Telemetry: 802.11 based, 800 m LOS
Safety Controller: 2.4 GHz, 800 m LOS, 4KM Max
Flight control software: Fully autonomous flight Auto takeoff and landing Unlimited waypoints with in flight retaking Failsafe “return to home” Long range telemetry* up to 30Km or through 3G network or satellite link

*Standard telemetry: 1.5 Km. Optional telemetry: 3-30 Km. Applies to all models.
